Large-diameter RF probe for high-power RF test fixtures and coaxial interface testing. Inner contact resistance stays at or below 3 mΩ.
| Overall Length | Plunger Diameter | Contact Resistance | Temperature Range | Durability |
|---|---|---|---|---|
| 33.50 mm | Ø7.00 mm | ≤3 mΩ (inner) | −13°F–572°F | ≥10,000 cycles |
| Specification | Details |
|---|---|
| Overall Length | 33.50 mm |
| Plunger Diameter | Ø7.00 mm |
| Contact Resistance | ≤3 mΩ (inner) |
| Temperature Range | −13°F–572°F |
| Durability | ≥10,000 cycles |
