SMT/SMD Pogo Pin Connector
Promax Pogo Pin manufactures SMD/SMT pogo pin connectors with 2 to 24 pins, from 3.4 mm to 47.7 mm in length. Working heights span 0.6 mm to 20.5 mm, and the contacts carry 1A to 5A per pin. Spring force runs 25 gf to 150 gf, with Au 3u to Au 40u plating. Every connector is CNC-machined in our Dongguan facility under ISO 9001 control.
SMD/SMT Pogo Pin Connectors: Product Range
SMD/SMT Pogo Pin Connector - NC691-08RB
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4638-03RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4623-03RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1.5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4530-02RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4528-04RA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4528-04PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4486-05RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4476-08RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4439-02RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4423-04PA
| Specification | Value |
|---|---|
| Plating | Au 20u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4202-04RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC4165-05PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3973-06PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 3A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3972-06PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1.5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3846-04PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3640-05RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3623-03RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3605-05PA
| Specification | Value |
|---|---|
| Plating | Au 40u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3569-04RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3557-03RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3552-24RA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3505-12PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3503-12PA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3457-04RA
| Specification | Value |
|---|---|
| Plating | Au 40u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3317-02RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3260-04RA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 3A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3243-06RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3167-07RA
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3166-10RA
| Specification | Value |
|---|---|
| Plating | Au 40u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC3087-06RA
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC2970-10A
| Specification | Value |
|---|---|
| Plating | Au 40u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC2921-02RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC2747-02RA
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - NC2180-04PA
| Specification | Value |
|---|---|
| Plating | Au 30u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 3A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C969-10R
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C935-02
| Specification | Value |
|---|---|
| Plating | Au 40u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C856-07P
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C715-24R
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C652-20R
| Specification | Value |
|---|---|
| Plating | Au 16u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2.5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C616-16R
| Specification | Value |
|---|---|
| Plating | Au 16u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2.5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C515-02RB
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1.2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C512-08R
| Specification | Value |
|---|---|
| Plating | Au 16u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C501-12R
| Specification | Value |
|---|---|
| Plating | Au 16u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2.5A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C360-06P
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C231-05P
| Specification | Value |
|---|---|
| Plating | Au 15u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C2281-03
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C2111-10
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C2111-04
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C1925-03R
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C1608-04R
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C158-04R
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C1358-06R
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C1174-03
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C107-04P
| Specification | Value |
|---|---|
| Plating | Au 5u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C1056-05P
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C083-02R
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C071-02
| Specification | Value |
|---|---|
| Plating | Au 10u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 2A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
SMD/SMT Pogo Pin Connector - C031-10
| Specification | Value |
|---|---|
| Plating | Au 3u" |
| Rated voltage (each contact) | 12V |
| Rated current (each contact) | 1A |
| Mechanical life | 10000 times |
| Operating temperature range | - 40 ~ 85 ℃ |
| Humidity range | 10%RH~90%RH |
How to Choose the Right SMD/SMT Pogo Pin Connector
An SMD/SMT pogo pin connector reflows onto the board surface like any other surface-mount part. The right connector depends on your pin count, working height, current, and plating. Use the steps below to lock in your spec before you request samples.
- Set the pin count for your signal map. Our SMD/SMT connectors run from 2 to 24 pins. Pick the count that covers every signal and power line in your interface. Send your pinout and we’ll match the layout.
- Match the connector length to your footprint. These connectors run 3.4 mm to 47.7 mm long and 0.9 mm to 12.5 mm wide. Pick a body that fits the board edge without crowding nearby parts. Share your footprint for a fit check.
- Set the working height for reliable compression. Working height ranges from 0.6 mm to 20.5 mm. Spec the height where the pins hold firm contact without bottoming out. We’ll model the travel against your mating gap.
- Choose the current rating for your load. SMD/SMT connectors carry 1A to 5A per pin. Match the rating to your peak load and leave headroom for in-rush. We widen the barrel and plating when your design needs more.
- Pick the spring force for stable contact. Spring force runs 25 gf to 150 gf across the range. Higher force scrubs through oxide and holds contact under vibration. Lighter force suits low-insertion-force docks.
- Choose the plating for your signal and cycle life. Plating spans Au 3u to Au 40u. Thicker Gold holds low resistance across high mate counts. Tell us your cycle target and signal need for the right thickness.
- Not sure which connector fits? Talk to our engineers. Send us your pinout, footprint, and working height. We’ll match a catalog connector or design a custom SMD/SMT pogo pin connector. Free samples ship within two weeks.
SMD/SMT Pogo Pin Connector FAQs
What is an SMD/SMT pogo pin connector?
An SMD/SMT pogo pin connector reflows onto the board surface like a standard surface-mount part. It gives a spring-loaded contact for docking, charging, or board-to-board links. It suits thin, space-tight designs that can’t take through-hole pins.
How many pins can these connectors have?
Our SMD/SMT connectors run from 2 to 24 pins. We lay out the contacts to match your signal and power map. Send your pinout for an exact build.
What current can an SMD/SMT connector carry?
Each pin carries 1A to 5A depending on diameter and plating. We size the barrel and plating to your load. Send your peak current for the right spec.
What plating options are available?
Plating runs from Au 3u to Au 40u for low, stable resistance. Thicker Gold extends wear life on high-cycle docks. Tell us your mate count and environment for a recommendation.
How reliable is the contact over many cycles?
Spring force of 25 gf to 150 gf scrubs oxide for a stable contact across the mate life. Thicker Gold plating holds resistance low as the pin wears. We tune force and plating to your cycle target.
What's the minimum order quantity?
We support low-volume prototype runs for qualification, then scale to production. Production runs typically start in the low thousands. Send your annual forecast for pricing.
How fast can I get samples?
Free samples ship within two weeks of an approved design. We return engineering feedback within 1–3 days. Promax holds ISO 9001, ISO 14001, ISO 45001, and IECQ QC080000.
Need pogo pins fast? Talk to an engineer
Get a custom quote, spec matching, and manufacturing guidance—without slowing down your project.
- ISO 9001 / 14001 / 45001 + IECQ QC080000
- Manufacturing Since 2014
- Free samples
- Mass production in 15–20 days
